In the ICU, clinical examination is often limited and chest X-rays frequently give us more confusion than clarity. This is where Point of Care Ultrasound (POCUS) becomes a true bedside extension of clinical reasoning rather than just another investigation.
Through a series of ICU-based scenarios, Dr. Payel Bose explains how lung and cardiovascular ultrasound can guide real-time decision-making in critically ill patients.
Case 1: When Oxygen Requirements Suddenly Rise
A 69-year-old man with long-standing hypertension and ischemic cardiomyopathy (EF 35%) is admitted with septic shock secondary to pyelonephritis. Initial management includes broad-spectrum antibiotics, norepinephrine, and nearly three litres of crystalloid resuscitation.
Over the next few hours:
- His oxygen requirement steadily increases
- PF ratio drops from 280 to 160
- Auscultation reveals bilateral crackles, though interpretation is difficult
- Chest X-ray shows bilateral hazy opacities, reported as nonspecific
At this point, lung ultrasound is performed.
Lung Ultrasound Findings
- Diffuse bilateral vertical hyperechoic artifacts arising from the pleural line
- These artifacts extend to the bottom of the screen and erase A-lines
- Lung sliding is preserved
- Pleural line is smooth and continuous
- No focal consolidations or pleural effusion
These findings are classic B-lines, seen diffusely across both lungs.
Final Diagnosis: Pulmonary Edema
B-lines represent increased fluid in the alveolar–interstitial space. In a patient with septic shock, underlying systolic dysfunction, and aggressive fluid resuscitation, diffuse bilateral B-lines strongly point toward pulmonary edema, most likely cardiogenic or mixed septic-cardiogenic.
Why Other Options Don’t Fit
- Pneumothorax: Lung sliding is present, which essentially rules it out
- Lung consolidation: Would show a tissue-like pattern with air bronchograms
- ARDS: Typically produces patchy B-lines, pleural irregularity, spared areas, and small subpleural consolidations
The ultrasound pattern here clearly favours fluid overload rather than inflammatory lung injury.
Understanding Lung Artifacts in Simple Terms
Lung ultrasound relies mainly on artifacts:
- A-lines: Horizontal lines → normal aerated lung
- B-lines: Vertical lines (“lung rockets”) → interstitial fluid
Distribution matters:
- Diffuse bilateral B-lines: Pulmonary
- Focal B-lines: Pneumonia or lung contusion
- Widely spaced B-lines: Interstitial fibrosis
Lung Ultrasound Scoring System
Lung aeration can be graded:
- Score 0: Normal lung sliding, A-lines present
- Score 1: Multiple discrete B-lines
- Score 2: Coalescent B-lines (white lung)
- Score 3: Lung consolidation with tissue-like appearance
BLUE Protocol: Rapid Bedside Assessment of Hypoxia
The BLUE protocol helps narrow down causes of acute dyspnea using lung profiles:
- A-profile: A-lines with lung sliding → asthma/COPD
- B-profile: B-lines with lung sliding → pulmonary edema
- C-profile: Consolidation → pneumonia
- Absent sliding with A-lines: Pneumothorax
It does not give a perfect diagnosis but strongly guides clinical direction, especially in emergencies.
Case 2: Sudden Collapse After Central Line Placement
A 56-year-old woman with severe ARDS suddenly develops:
- Hypotension
- Tachycardia
- Increased peak airway pressures
- Rapid fall in oxygen saturation
Lung Ultrasound Findings
- Absent lung sliding on the right anterior chest
- Prominent A-lines
- On lateral scanning, an area where lung sliding alternates with absent sliding
Key Diagnostic Sign: Lung Point
The lung point represents the boundary between collapsed lung and pneumothorax.
It is 100% specific for pneumothorax.
Important Clarification
- Absent lung sliding alone is not diagnostic
- Lung sliding may be absent in apnea, mainstem intubation, pleural adhesions, fibrosis, or low-tidal-volume ARDS
- Lung point confirms pneumothorax, though it may be absent in massive pneumothorax
Case 3: Consolidation or Atelectasis?
A 74-year-old ventilated patient with severe pneumonia develops worsening sepsis and a right lower-zone opacity on X-ray.
Ultrasound Findings
- Subpleural hypoechoic region
- Tissue-like (liver-like) echo pattern
- Dynamic air bronchograms moving with respiration
- Minimal pleural effusion
Diagnosis: Lung Consolidation
Dynamic air bronchograms indicate patent bronchi with air movement, strongly suggesting inflammatory consolidation (pneumonia).
In contrast:
- Atelectasis shows static air bronchograms due to airway obstruction
Case 4: Hypovolemia and IVC Assessment
A 43-year-old man presents with profuse vomiting and diarrhea:
- Hypotension
- Elevated lactate
- No cardiac history
Ultrasound Findings
- IVC diameter ~2 cm with >60% inspiratory collapse
- Normal cardiac function
- Predominant A-line lung pattern
Interpretation
In spontaneously breathing patients, an IVC collapse >50% suggests low right atrial pressure and fluid responsiveness, consistent with hypovolemic shock.
Case 5: IVC in Mechanically Ventilated Patients
A 61-year-old man with septic shock remains hypotensive despite vasopressors.
Ultrasound Findings
- Normal LV systolic function
- IVC distensibility index ≈22%
Key Rule
In mechanically ventilated patients:
- IVC distensibility >18% predicts fluid responsiveness
This assessment is reliable only when:
- Patient is sedated and paralyzed
- Sinus rhythm is present
- Controlled ventilation with adequate tidal volume
Key Clinical Takeaways
- POCUS is a clinical reasoning tool, not just an imaging modality
- Lung ultrasound rapidly differentiates pulmonary edema, pneumothorax, ARDS, and consolidation
- IVC interpretation depends heavily on ventilation status
- Patterns and clinical context matter more than isolated signs
When used thoughtfully, POCUS brings clarity to complex ICU decisions—right at the bedside.
